MZ-QLB960NE - Samsung 983 DCT Series SSD 960GB - PCIe NVMe 2.5” 7mm Interface Internal Solid State Drive with V-NAND Technology for Business
Samsung's 983 DCT is a high-performance solution for servers that need enhanced data reliability to safeguard critical data, from content delivery networks (CDNs) to big data, artificial intelligence (AI) and Internet of Things (IoT) applications. Available in two form factors, U.2 and M.2., the 983 DCT’s NVMe interface empowers blazing-fast speed, high responsiveness and a high Quality of Service (QoS). And with power-loss protection and end-to-end data protection, you get a highly reliable enterprise storage solution backed by a 5-year limited warranty up to 1,366 TBW.
983 DCT 960GB NVMe SSDs in the U.2 form factor deliver blazing fast sequential read/write speeds up to 3,000/1,050 MB/s and random read/write speeds up to 400/40K IOPS. They also support PCI Express® (PCIe) Gen 3 x 4 lanes to provide high bandwidth and low latency.
Detect signal discrepancies and proactively remedy them in real time with the Error Correcting Code (ECC) engine. Secure data without performance degradation thanks to AES 256-bit encryption.
Protect data integrity from unexpected power loss with Samsung's advanced power-loss protection architecture. Using the electricity from a tantalum capacitor to provide enough time to transfer the cached data in the DRAM to the flash memory, you can be assured no loss of data.
| General Information | |
| Product Name | Samsung 983 DCT Series MZ-QLB1T9NE 1.92TB PCIe NVMe 2.5" Internal Enterprise SSD |
| Product Series | 983 DCT |
| Product Model | MZ-QLB1T9NE |
| Product Type | Solid State Drive |
| Technical Information | |
| Storage Capacity | 1.92 TB |
| Interfaces/Ports | |
| Drive Interface | U.2 (SFF-8639) NVMe |
| Drive Performance | |
| Maximum Read Transfer Rate | 3400 MB/s |
| Maximum Write Transfer Rate | 2200 MB/s |
| Network & Communication | |
| Wireless LAN | No |
| Physical Characteristics | |
| Drive Type | Internal |
| Form Factor | 2.5" |
| Other Information | |
| Product Family | 983 DCT |
Application for QM2 SSD slots:
Configured system orders start here!
The selected drives are batch controlled and tested using our HDD and SSD servers. Passed drives are then installed in the NAS with Volume and RAID set. Our pre-burn testing prepares the NAS with an initial system and drive testing cycle to ensure that the integrity of the entire system is tested and passed with no issues at all.
Our stress testing (burn-test) cycle commences for a minimum of 24 hours and extends to 48 hours if requested or required. This is undertaken in order to ensure stability when used in a normal environment. These tests can include extremes of workload (constant I/O's), CPU and memory use, thermal load (heat), clock speed, or voltages, bus and connectivity components, with the primary stress testing software aiming to test stability by trying to force a system to fail. Our tests put a greater emphasis on robustness, availability and error handling heavy loads.
Once the tests are complete we QA and pack the system back into it's retail box. Then it's double boxed to protect the unit during shipping. You receive your QNAP NAS Ready To Plug 'N' Store. It doesn't get any easier. Buy your NAS from the QNAP EXPERTS at QNAP DIRECT.
